// WDT, permet le redémarrage automatique en cas de blocage inattendu, qui peut être causé par le décodage JPEG.
#define ENABLE_WDT
// select setting
#include "settings.h"
#include <time.h>
#include <WiFi.h>
#include <esp_jpg_decode.h>
#include <esp_task_wdt.h>
#include <SPI.h>
#include <HTTPClient.h>
/* display settings */
#include <Arduino_GFX_Library.h>
#define TFT_BL 22
Arduino_DataBus *bus = new Arduino_ESP32SPI(27 /* DC */, 5 /* CS */,18 /* SCK */, 23 /* MOSI */, GFX_NOT_DEFINED /* MISO */);
Arduino_GFX *gfx = new Arduino_ILI9341(bus,33 /* RST */, 1 /* rotation */);
static int len, offset;
HTTPClient http;
//***************************************//
// SETUP //
//***************************************//
void setup()
{
Serial.begin(115200);
gfx->begin();
gfx->fillScreen(BLACK);
Serial.println("Connecting WiFi .");
WiFi.begin(ssid, password);
while (WiFi.status() != WL_CONNECTED)
{
delay(500);
Serial.print(".");
}
Serial.println(" CONNECTED");
#ifdef TFT_BL
pinMode(TFT_BL, OUTPUT);
digitalWrite(TFT_BL, HIGH);
#endif
#ifdef ENABLE_WDT
// set WDT timeout a little bit longer than HTTP timeout
esp_task_wdt_init((HTTPCLIENT_DEFAULT_TCP_TIMEOUT / 1000) + 2, true);
enableLoopWDT();
#endif
}
//******************************************//
// LOOP //
//******************************************//
void loop()
{
if (WiFi.status() != WL_CONNECTED)
{
// wait for WiFi connection
delay(500);
}else{
Serial.print("[HTTP] begin...\n");
//http.begin(url);
http.begin(URL);
Serial.print("[HTTP] GET...\n");
int httpCode = http.GET();
Serial.printf("[HTTP] GET... code: %d\n", httpCode);
// HTTP header has been send and Server response header has been handled
if (httpCode <= 0)
{
Serial.printf("[HTTP] GET... failed, error: %s\n", http.errorToString(httpCode).c_str());
}
else
{
if (httpCode != HTTP_CODE_OK)
{
Serial.printf("[HTTP] Not OK!\n");
delay(5000);
} else {
// get lenght of document (is -1 when Server sends no Content-Length header)
len = http.getSize();
Serial.printf("[HTTP] size: %d\n", len);
if (len <= 0)
{
Serial.printf("[HTTP] Unknow content size: %d\n", len);
} else {
// get tcp stream
WiFiClient *http_stream = http.getStreamPtr();
esp_jpg_decode(len, JPG_SCALE, http_stream_reader, tft_writer, http_stream /* arg */);
}
}
}
http.end();
delay(5000);
}
#ifdef ENABLE_WDT
// notify WDT still working
feedLoopWDT();
#endif
}
//*********************************************************************************
static size_t http_stream_reader(void *arg, size_t index, uint8_t *buf, size_t len)
{
WiFiClient *http_stream = (WiFiClient *)arg;
if (buf)
{
//Serial.printf("[HTTP] read: %d\n", len);
size_t a = http_stream->available();
size_t r = 0;
while (r < len)
{
r += http_stream->readBytes(buf + r, min((len - r), a));
}
return r;
}
else
{
// Serial.printf("[HTTP] skip: %d\n", len);
int l = len;
while (l--)
{
http_stream->read();
yield(); // <=========================================
}
return len;
}
}
//***********************************************************************************************
static bool tft_writer(void *arg, uint16_t x, uint16_t y, uint16_t w, uint16_t h, uint8_t *data)
{
if (data)
{
//Serial.printf("%d, %d, %d, %d\n", x, y, w, h);
gfx->draw24bitRGBBitmap(x, y, data, w, h);
}
#ifdef ENABLE_WDT
// notify WDT still working
feedLoopWDT();
#endif
return true; // Continue to decompression
} |
Répondre avec citation
Envoyé par cobra38
