| from part import *
from material import *
from section import *
from assembly import *
from step import *
from interaction import *
from load import *
from mesh import *
from optimization import *
from job import *
from sketch import *
from visualization import *
from connectorBehavior import *
import random
from array import *
from odbAccess import openOdb
import odbAccess
import math
import numpy
import os # Operating system
import shutil # copying or moving files
from abaqusConstants import*
Max_iterations=61
#Open text file to write results
sortie = open('Results_fromODB.txt' , 'w')#text file to fine the results
sortie.write('\t Property of Not Real Engineering')
sortie.write('\n')
for q in range(1, Max_iterations):
odbname='cyl_cantilver_c%d' %(q) # set odb name here
path='./' # set odb path here (if in working dir no need to change!)
myodbpath=path+odbname+'.odb'
odb=openOdb(myodbpath)
step1 = odb.steps['Step-1']
#create a historyRegion for a specific point(Node1017)
hRegionStep1=step1.HistoryRegion(name='historyNode1017',description='Displacement and reaction force',point=instance1.nodes[1017])
#create variables for this history output in step1
hOutputStep1U2=hRegionStep1.HistoryOutput(name='U2',description='Displacement', type=SCALAR)
hOutputStep1Rf2=hRegionStep1.HistoryOutput(name='Rf2',description='Reaction Force', type=SCALAR)
#Add history data for step1
timeData1=[0.0, 1.0]
u2Data=[0.0, 1.0]
rf2Data=[0.0, 1.0]
hOutputStepU2.addData(frameValue=timeData1,value=u2Data)
hOutputSteprf2.addData(frameValue=timeData1,value=rf2Data)
odb.close()
sortie.close() |
